Products > Upper Limb Prostheses > Myoelectric Upper Limb Prostheses > Forearm Myoelectric Hand System with Five Fingers (One-Motion Freedom)
Product name : Forearm Myoelectric Hand System with Five Fingers (One-Motion Freedom)
Product No. : FW--001S
←[Previous Product]              [Next Product]→
Online Inquiry         Email Us

  Details:

Myoelectric Arm Prostheses (Wrist Universal Rotate 360°)

Myoelectric Arm Prostheses (Wrist Universal Rotate 360°)

Technical Parameters:

S: Total length 152mm, Weight 350g
M: Total length 157mm, Weight 360g
L: Total length 162mm, Weight 370g
Skin color range: International version 1-18
Battery capacity: 750mAh
Grip: 35N-60N
Power supply: 7.4V
The wrist rotates 360 degrees and the wrist function is ±30 degrees, replacing the two-degree- of-freedom forearm prosthesis on the market.
(Alternative advantage: large angle of movement, coexistence of wrist and wrist rotation, light weight, and easy operation)

Product Function:

Fingers can open and grasp.
Wrist can be passively rotated with friction or be fixed.
Suitable for any part amputation below elbow.

Attached Accessories:

Including: a pair of sensors or electric switches, two pcs of sensor modules or electric switch modules, two batteries, one battery box, one battery box module, one battery charger adapter, one charger base, one silicone glove, one myoelectric hand skeleton, Product Qualification Certificate, Prosthetic Product Warranty Card, Product Quality Tracking Card, Operating Manual of Myoelectric Hand.
